Electrical Specifications

• Impedance: 50 Ω nominal Or  75 Ω nominal
• Frequency Range: 0-4 GHz with low reflection
• Voltage Rating: 500 volts peak
• Dielectric Withstanding Voltage: 1,500 volts rms
• VSWR :Straight connectors: 1.3 max 0-4 GHz
• Right angle connectors: 1.35 max 0-4 GHz
• Contact Resistance
• Center contact: 1.5 mΩ;
• Outer contact: 0.2 mΩ
• Insulation Resistance: 5,000 MΩ
• Braid to Body: 0.1 milliohm
• RF Leakage: -55 dB min at 3 GHz
• Insertion Loss: 0.2 dB min at 3 Ghz

Material
Male Contact: Brass
Female Contact: Beryllium copper or phosphorous bronze,silver or gold-plated
Other Metal Parts: Brass, nickel finish
Insulator: TFE
Crimp Ferrule: Copper/brass
