FEATURES

• Data-rate of 1.25Gbps operation
• 850nm VCSEL laser and PIN photodetector
• Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
• Digital Diagnostic Monitoring:
• Internal Calibration or External Calibration
• 500m transmission with 50/125μm MMF
• 300m transmission with 62.5/125μm MMF
• Compatible with RoHS
• +3.3V single power supply
• Operating case temperature:
• Standard: 0 to +70°C
• Industrial: -40 to +85°C
