MATERIAL

• Coupler Housing : ABS High-Impact UL94V-0 Thermoplastic
• Contact : 3U’’ Gold-Plated.
• Color : White
• RoHS Compliant

PHYSICAL CHARACTERISTICS

• Durability Matingcycle : 1000 Cycles Min.
• Insertion Force : 4.5Kgf Max.
• Withdraw Force : 0.5Kgf-4Kgf.
• Operation Temperature :-55°C to 85°C.

ELECTRICAL

• Contact Current Rating : 0.5A Min.
• Voltage Rating : 40V AC(RMS)
• Insulation Resistance : 100M ohms Min.
• Contact Resistance : 2 Ohm Max.
• Dielectric With Standing Voltage : 300 V. AC.
