FEATURES

• Meeting the ANSI/TIA-568-C.2 Category 3, ISO/IEC11801 and EN50173-1 specification.
• Supports T568 A&B wiring & easy installation.
• IDC connector can accept 23-26 AWG solid and stranded cables.
• Industry standard tools like (110 or Krone punch down tools ).
• Wire manage hole for easy to manage wires with cable ties.
• RoHs Compliant

ELECTRICAL & PHYSICAL SPECIFICATIONS

• IDC Contact: 0.8mm thickness Phosphor Bronze,tin plating over nickel
• Jack Operating life : minimum 750 insertions
• High impact plastic housing, UL 94V-0
• Jack Contact : Phosphor Bronze,50μinch thickness gold plated over nickel
• IDC Operating life : minimum 200 insertions
• PCB : FR-4,1.6mm thickness
• Dielectric Strength : 1000V RMS for 1min
• Insulation Resistance : 10MΩ min
• Contact Resistance : 2mΩ per contact
• Temperature Range : -10 C to 60 C max
• Humidity : 10%-65%
